Encoding Method:Incremental

Resolution:200 P/R

Shaft Diameter:20 mm

Cable Length:1 meter

Power Supply Voltage:5 to 24 VDC

Ripple (p-p):5% max.

Output Type:NPN open collector

Environmental Temperature Range:-20°C to +60°C

Weight:Approx. 150 g

    The OMRON E6H-CWZ3X Hollow Shaft Line Driver Encoder is engineered for high-performance applications requiring precise positioning and monitoring. It is equipped with a robust hollow shaft design, ensuring compatibility with various machinery configurations. This encoder is particularly suited for use in industrial automation, where reliability and accuracy are paramount.

    With a resolution of 1,024 counts per revolution, the E6H-CWZ3X provides unparalleled precision, making it ideal for applications demanding high-resolution feedback. Its wide operating temperature range ensures stable performance across various environments, from cold storage facilities to hot manufacturing floors.

    Featuring an open-collector output and an M12 connector, this encoder facilitates easy integration into existing control systems. The compact design and versatile connector allow for quick installation and setup, saving valuable time and resources during system implementation.

    Built with durability in mind, the OMRON E6H-CWZ3X Hollow Shaft Line Driver Encoder withstands harsh industrial conditions without compromising on performance. Its construction includes robust materials that resist wear and tear, ensuring longevity even in the most challenging environments.

    To maximize efficiency, the encoder utilizes a patented technology that minimizes power consumption, reducing overall energy costs without sacrificing performance. This makes it an eco-friendly choice for businesses committed to sustainability and cost-effectiveness.
